Flat angle, for device installation trunking Rapid 45-2 type GK-53130

Item no. / Types

Width	130 mm

Height	53 mm

Colour

Product description

Product description

Flat angle for changing the direction of the Rapid 45-2 device installation trunking.

Technical data

Angle range, max.	90 mm
Angle range, min.	90 mm
Antibacterial treatment	no
Cable retaining clip	no
Change of direction	Vertical, rising/falling
CO2 Footprint (GWP) Cradle-to-Gate	1,8558 kg CO2e / 1 Piece
Colour	Pure white; RAL 9010
Cover mounting type	Internal
Cover width	45 mm
Cover width 2	45 mm
Dimension	200x200x130
Duct connector	no
for duct width	130 mm
for trunking height	53 mm

Halogen-free	no
Height	53 mm
Length	225 mm
Material	Polyvinylchloride
Mounting perforation in base	yes
Number of covers	2
Permitted temperature range, max.	60 °C
Permitted temperature range, min.	-15 °C
Protection rating	IP40
Protection rating IK code	IK08
Protective film	yes
Symmetrical	yes
Version for	Base and cover
Width	130 mm
