Technical data
| Cable type for surge protection devices |
Power cable AV
|
| Dimension |
255V
|
| Installation type |
Wall socket
|
| Lightning protection zone LPZ |
2→3
|
| Maximum back-up fuse |
16
A
|
| Maximum continuous voltage AC |
255
|
| Maximum discharge current (8/20 μs) |
6
kA
|
| Network form |
Other
|
| Nominal discharge current (8/20 µs) |
3
kA
|
| Nominal voltage AC (50/60 Hz) |
230
V
|
| OBO_Nominal load current (input/output terminal) |
16
A
|
| Operating temperature, max. |
60
°C
|
| Operating temperature, min. |
-15
°C
|
| Pole version |
1
|
| Response time |
<25
ns
|
| Signalling on device |
Acoustic
|
| SPD to EN 61643-11 |
Type 3
|
| SPD to IEC 61643-1 |
Class III
|
| Version for |
V connection
|
Connectivity options
| Max. mains-side overcurrent protection |
16
|
| Protection level [L-N] |
≤1,3
|
