Unperforated cover A4

Item no. / Types

Length	3000 mm

Width

Plate thickness

Product description

Product description

Cover for cable trays and mesh cable trays.
When using covers outdoors, additional measures against the influence of wind must be taken.

Transverse bead from 500 mm width.

Technical data

CO2 Footprint (GWP) Cradle-to-Gate	3,2358 kg CO2e / 1 Meter
Colour	stainless steel
Dimension	50x3000
Dimension B	50 mm
Fastening type	Cover clamp
Height	13 mm
Length	3000 mm
Maintain electrical functions	no
Material	Stainless steel 1.4571

All types

All types

Types	Length	Width	Plate thickness	Item no.	Quantity	SSU
DRLU 050 A4	3000 mm	50 mm	1 mm	6052978	m	3 m
DRLU 100 A4	3000 mm	100 mm	1 mm	6052991	m	3 m
DRLU 200 A4	3000 mm	200 mm	1 mm	6052993	m	3 m
DRLU 300 A4	3000 mm	300 mm	1 mm	6052994	m	3 m
DRLU 400 A4	3000 mm	400 mm	1 mm	6052995	m	3 m
DRLU 500 A4	3000 mm	500 mm	1.25 mm	6052996	m	3 m
DRLU 600 A4	3000 mm	600 mm	1.25 mm	6052998	m	3 m

Accessories

Products	Types	Item no.	Quantity	SSU
Cover clamp, universal A2	DKU A2	6065600	piece	20 piece
Turn buckle A2	AZDR 50 A2	6065309	piece	10 piece
Tightening strap A2K Jet black	SBR 8 A2K	6490192	m	40 m
Tightening strap A2K, Jet black	SBR 15 F1K	6490282	m	25 m
