Walkable cable cover 3000 | 141 | 2
morepic-1 morepic-2

Walkable cable cover

Item no. 6049229 | EAN 4012197446185

6049229 / DDBKR FS
3000 mm
141 mm
2 mm
Product description
Product description
Walkable cable cover for the protection of cables and lines on the floor. Lightweight roof, corrugated sheet steel, direct floor mounting in indoor areas.
  • Communautés Européennes, EC declaration of conformity according to EC directives
  • CO₂ footprint (PCF)
Technical data

Technical data

CO2 Footprint (GWP) Cradle-to-Gate 5,8558 kg CO2e / 1 Meter
Colour zinc
Dimension 141x23x3000
Dimension B 141 mm
Dimension L 3000 mm
Dimension W 141 mm
Height 23 mm
Length 3000 mm
Material Steel
Plate thickness 2 mm
Surface Strip galvanized
Width 141 mm
All types

All types

Types Length Width Plate thickness Item no. Quantity SSU
DDBKR FS 3000 mm 141 mm 2 mm 6049229
3 m
Downloads

Download

EU declaration of conformity DDBKR FS / 6049229 , 0.10MB , pdf
Download

DDBKR FS / 6049229
Download
